廠家供應紡織機械配套設備-驗布機-卷布機

產品特點/product features

1.適用于紡織、印染、服裝、合成革、針織、經編、低克重無紡布等織物的卷驗。

2.采用國內**雙變頻控制漲力，可任意調節松緊。

3.采用臺灣液壓系統和光電自動對邊。

4.采用國內***的電子計長控制儀。

5.機器可配裝：1>電子稱 2>erp疵點采集系統及打印裝置 3>卷取差速裝置 4>自動錯邊功能 5>無布自停功能 6>卷取差速裝置 7>色標對邊 8>電腦接口 9>自動裁刀

1.it is suitable forrolling test of fabricbrics including textile,dyeing & finishing,clothing,synthetic leather,knit,warp knitting,low-weight non-woven fabric etc.

2.it adopts domestic originated double frequency tension controller which the tension is adjustable.

3.it adops taiwan hydraulic system and automatic infrared photoelectric side flushing.

4.it adopts most advanced electronic length controller in china.

5.assembling:1>electronic scale  2>erp defect sampling system and printing equipment   3>meta detector   4>automatic misalignment function  5>automatic stop with absence of fabrics  6>winding differential speed device  7>side flushing whth color code  8>computer lnterface  9>automatic cutting knife

技術參數/technical parameters

1.試用幅寬：1800mm-3600mm

2.卷取直徑：≤600mm

3.卷驗速度：0-100m/min

4.糾偏類型：液壓

5.主機功率：0.75/0.4-2.2/0.75（kw）

6.整機功率：3kw-4kw

7.漲力控制：雙變頻

8.外觀尺寸：(l×w×h)2800×2000×1980(mm)

1.applicable width:1800mm-3600mm(optional)

2.winding diameter:≤600mm

3.winding & testing speed:0-100m/min

4.type of deviation correction:hydraulic pressure

5.main motor power:0.75/0.4-2.2/0.75(kw)

6.whole machine power:3kw-4kw

7.type of tension control:dual vf

8.outline dimensiom:(l×w×h)2800×2000×1980(mm)
