電腦無梭多功能絎縫機 型號：HY-W-DGN

用途：絎縫高級床墊、床上用品、居家裝飾等各種各樣花紋 參數 (單位：mm)： 主機尺寸（長×寬×高）：4820×1650×2060 絎縫寬度：2450 針排距：76.2,76.2,152.4(6”) 針距：25.4 行程：535 絎縫厚度：≤60 （所有圖案） 步長：3-8 生產速度：60-230（米/小時） 車針型號：24/180 23/160 22/140 21/130 主軸轉速：200-980（轉/分鐘） 功率：7KW 電壓：380V/50HZ 220V/60HZ 全機重量：5500kg 具體信息： • 在具備多針絎縫機所有功能的基礎上兼具單針絎縫功能 • 比單針絎縫機有更高的產量，比多針絎縫機有更多的圖案 • 采用無梭絎縫機構，避免頻繁更換底線，絎縫線跡更扎實 • 針排和壓板采用無凸輪的雙擺臂運動機構，避免潤滑油玷污布料的事故發生 • 面，底線斷線紅外線檢測自動停機，自動提針及數控調速 • 通過CE認證的安全保護標準 • 新一代電腦控制系統，絎縫精度高，絎縫過程中無需過多的參數調整或修改圖案 • 強大的花模組合及多次跨步功能，可在同一行的位置絎縫出各種不同的圖案 • 狀態檢測，機器的運行情況一目了然 Purpose:It is widely used for quilting high-quality mattresses, quilt covers, and household ornaments. Different patterns are available. Parameter(Unit mm)： Dimension(L×W×H) ：4820×1650×2060 Quilting width：2450 Space between needle rows: 76.2,76.2,152.4(6”) Space between needles：25.4 X-axis movement displacement：535 Thickness of quilting≤60(for all patterns) Stitch length：3-8 Speed of operation：60~230(m/hour) Model of needle：24/180 23/160 22/140 21/130 Quilting speed：200~980(RPM) Total power required：7KW Voltage ：380V/50HZ 220V/60HZ Gross weight：5500kg Detail Information: • Based on the Multi-needle Quilting Machines and with all the functions of Multi-needle Quilting Machine, at the same time also with the functions of single needle quilting . • With much more output comparing with Single Needle Quilting Machines and with more patterns comparing with Multi-needle Quilting Machines. • Adopting Chain stitch quilting mechanism, avoiding frequently replacing bottom thread, and making the quilting stitches much firmer. • Needle bar and press plate are controlled by a double- swinging device without cam avoiding lubrication and dirtying of material • Automatic stop motion control in case the top thread or the bottom thread breaks，automatic needle-lifting and CNC speed adjustment • CE Certificate • CNC precision control system, no need to adjust the press plate’s position when the thickness of quilting material varies • Strong functions of pattern-combining and Tack & Jump quilting to enable you to quilt different patterns in same row of the mattresses • Fault detection function for ease of determining the running state of the machine at any given time
